To download Brochure with spec see here
Specifications:
PROCESSOR
• Intel® N200, 3.7 GHz burst
OPERATING SYSTEM
• Microsoft® Windows 11
• Multiple languages supported (English, French, Spanish, German, Portuguese)
MEMORY AND DATA STORAGE
• 16 GB RAM (LPDDR5)
• 256 GB PCIe SSD
• User-accessible MicroSDXC card slot
GRAPHICS
• Intel® Gen12 UHD Graphics
DISPLAY
• Active viewing area: 7” (178 mm)
• Resolution: WXGA (1280 x 800)
• High-visibility backlit LCD for best-in-class sunlight view-ability
• Portrait or landscape orientation with automatic screen rotation
TOUCH SCREEN
• Projected capacitive multi-touch interface for use with gloves, small tip stylus, and in wet conditions
• Optically bonded for increased visibility and strength
• Chemically-strengthened Dragontrail™ High lon- Exchange (HIE™) cover glass for excellent impact and scratch resistance
KEYBOARD
• Adjustable LED backlit keys
• Four-way directional navpad
• Windows/home key
• Power key
• Enter key
• Three user-programmable function keys
PORTS
• USB-A (5Gbps) x 1
• USB-C (5Gbps) x 1
• 12 VDC power input jack
• Docking port connections (Power, USB 2.0)
• Loud output speaker for noisy environments
• Dual digital microphone input for improved clarity
BATTERY
• Removable Li-Ion battery, 43.2 Whr
• Operates up to 15 hours on one charge
• Removable battery, easily changeable in field
• Optimized for strong performance in cold temperatures
• Excellent lifecycle performance
PHYSICAL
• Size: 5.40” w x 8.48” I x 1.36” d (137 x 215 x 35 mm)
• Weight: 1.5lbs (680g) without swappable battery
• Durable, chemical- and shock-resistant design
• Easy-to-grip, impact-absorbing, overmolded bumpers
• Lightweight and ergonomic design
WIRELESS CONNECTIVITY
• Long-range Bluetooth® Smart Ready wireless technology, v5.3 + EDR, Class 1.5, BLE support
• Wi-Fi 6 (802.11 ax), 2.4 GHz and 5 GHz Wi-Fi 6E
• 4G LTE multi-carrier capable
CAMERA
• Rear: 13 MP with LED illumination
• Front: 5 MP
• Juniper Geotagging™: embed photo with date, time, and GNSS position
GPS/GNSS
• 2 to 5 meter typical accuracy
• Quectel LC79H
• Integrated real-time SBAS receiver (WAAS, EGNOS, etc.)
• 135 GNSS tracking channels
OTHER FEATURES
• Ambient light sensor
• Compass
• Accelerometer
• Gyroscope
• TPM (Trusted Platform Module) v2.0
CERTIFICATIONS AND STANDARDS
• FCC and ISED Certification (USA and Canada)
• FCC Class B and ICES-003 Class B (USA and Canada)
• CE Marking (EU Radio Equipment and RoHS Directives)
• ACMA RCM (Australia)
• United States Toxic Substances Control Act (TSCA)
• California Prop 65
• Canada Prohibition of Certain Toxic Substances
• EU REACH, EU POP, SCIP, WEEE
JUNIPER RUGGED™
• IP68 waterproof and dustproof
• Operating Temperature: -4° F to 122° F (-20° C to 50° C)
• Storage temperature: -22° F to 158° F (-30° C to 70° C)
• Shockproof: multiple drops from 4’ (1.2–1.5 m) onto concrete
• Designed to meet MIL-STD-810H test procedures: Method 501.7 High Temperature; Method 502.7 Low Temperature; Method 503.7 Temperature Shock; Method 507.6 Humidity; Method 514.8 Vibration; Method 516.8 Shock
WARRANTY
• 2-Year Warranty
• Service Plans Available
STANDARD ACCESSORIES
• Standard removable battery
• AC wall charger with international plug kit
• Capacitive small-tip stylus w/tether
• Hand strap
• Connector port dust cover
AVAILABLE ACCESSORIES
• Powered stylus
• Detachable keyboard
